LST LC-726 DMX AMPLIFIER

INTRODUCTION:

This is DMX programs LED controller. We provide DC12V and DC24V version. There are 6 outputs using SPEAKON sockets. Each output has three channels for LED PWM control.

The advantage of this unit is that you can set up different start DMX address for each output by own DIP switch.

There are two DMX groups input. You can select one and other will be back up in case of failure.

TECHNICAL SPECIFICATIONS:

Power supply:  220-240V AC 50/60Hz

Power consumption:  MAX. 720W

Fuse :   F10A/250V

Each channels output:  DC 12V 3A  Max. 10A     /    DC 24V 1.5A  Max. 5A

DMX controlled channels:  Total 18

DMX 512 connection:  3-Pin XLR

Dimensions:  485x88x375mm

Weight:  5.89 kg
